Resolution (MP) |
5 |
|
|
Resolution (H x V) |
2448 x 2048 |
|
|
Sensor |
Sony IMX547 |
|
|
Sensor Size (Diagonal) |
Type 1/1.8 (8.8 mm) |
|
|
Optical Format |
— |
|
|
Sensor Type |
High Speed CMOS Image Sensor |
|
|
Pixel Size |
2.74 µm x 2.74 µm |
|
|
Interface |
Camera Link Base / Medium / Full / 10 Tap |
|
|
Max Frame Rate |
2 Tap: |
31.0 fps |
|
|
4 Tap: |
61.2 fps |
|
|
8 Tap: |
109.5 fps |
|
|
10 Tap: |
109.5 fps |
|
Exposure Time (1 µs step) |
1 µs – 60 s |
|
|
Partial Scan (Max Speed) |
1374.1 fps at 16 Lines (8 bit) |
|
|
Pixel Data Format |
Mono 8 / 10 / 12 bit |
|
|
Electronic Shutter |
Global |
|
|
Digital Gain |
1x – 32x |
|
|
Black Level Control |
0 – 255 LSB at 12 bit (1 LSB step) |
|
|
Exposure Mode |
Free-Run, Timed, Trigger Width |
|
|
External Trigger |
3.3 V – 24.0 V, 10 mA, Logical Level Input Optically Isolated |
|
|
Software Trigger |
Asynchronous, Programable via Camera API |
|
|
Dynamic Range |
71 dB |
|
|
Dimension |
40.0 mm x 40.0 mm x 50.0 mm |
|
|
Weight |
125 g |
|
|
Temperature |
Operating: 0° C – 40° C |
Storage: -40° C – 70° C |
|
Lens Mount |
C Mount |
|
|
Power |
11 – 24 V DC Typ 5 W |
|
|
Compliance |
CE, FCC, KC |
|
