VP-65MX-C 31 I

The VP-65MX is a new 65 megapixel CMOS camera available with the CoaXPress interface. This camera is based on the latest CMOS image sensor technology (GMAX3265) from Gpixel. The VP-65MX offers up to 31.6 frames per seconds at 9344 x 7000 resolution. This camera uses thermoelectric Peltier (TEC) cooling technology developed for and used by many demanding medical market customers. The TEC maintains the operating temperature of the image sensor at up to 15 degrees below ambient temperature. The VP-65MX camera provides a stable operating condition and the ability to expose for a long period of time to increase the camera’s sensitivity. Featuring high-speed and high-resolution with stable performance, this camera is ideal for demanding applications such as FPD, PCB and semiconductor inspections.

RESOLUTION (MP)65

RESOLUTION (HxV)9344 x 7000

FPS31

Sensor TypeGMAX3265

InterfaceCXP-6

ChromaColor

Thermoelectric Peltier Cooled – 15℃ below
65 Megapixel Resolution
CoaxPress Interface up to 31.6 fps at 25 Gbps using 4 CH
Global Shutter
Flat Field Correction
DSNU and PRNU Correction
Defective Pixel Correction

Flat Panel Display Inspection
Electronics Inspection
Semiconductor Inspection
Document and Film Scanning

Model	VP-65MX-M/C 31I
Resolution (H × V)	9344 × 7000
Sensor	Gpixel GMAX3265 – Normal Speed
Sensor Size (Diagonal)	29.9 mm × 22.4 mm (37.4 mm)
Pixel Size	3.2 μm × 3.2 μm
Interface	CoaXPress
Max. Frame Rate	4 CH: 31.6 fps @ 8 bit
	4 CH: 27.3 fps @ 10 bit
	4 CH: 24.1 fps @ 12 bit
	4 CH: 31.6 fps @ 8 bit 2 × 2 Binning
Exposure Time (1 μs step)	14 μs ~ 60 s
Partial Scan (Max. Speed)	6349.2 fps at 4 Lines
Binning	2 × 2 Binning
Pixel Data Format	Mono: Mono 8 / Mono 10 / Mono 12
Pixel Data Format	Color: GB Bayer 8 / GB Bayer 10 / GB Bayer 12
Electronic Shutter	Global Shutter
Trigger Synchronization	Free-Run, Hardware Trigger, Software Trigger or CXP
External Trigger	3.3 V ~ 24.0 V, 10 mA, Logical Level Input, Optically Isolated
Software Trigger	Asynchronous, Programmable via Camera API
Dynamic Range	66 dB @ 12 bit
Gain Control	1× ~ 32×
Black Level Control	0 ~ 255 LSB at 12 bit
Cooling Method	Thermoelectric Peltier Cooling
Cooling Performance	15°C below ambient temperature – Standard cooling with a fan
Dimension / Weight	90 mm × 90 mm × 145 mm, 1,500 g (with F-mount)
Temperature	Operating: 0°C ~ 40°C, Storage: -40°C ~ 70°C
Lens Mount	F-mount, Custom mount available upon request
Power	External: 11 ~ 24 V DC
Power	Dissipation: Typ. 26.0 W
Compliance	CE, FCC, KC
API SDK	Vieworks Imaging Solution 7.X
