VT-3K7G-H38

The VT-3K7G, the new hybrid Time Delayed Integration (TDI) line scan cameras equipped with the GigE interface, provide faster line rates and higher sensitivity than existing line scan cameras. With hybrid TDI line scan technology combining the strengths of both CCD and CMOS image sensors, the VT-3K7G camera features up to 35 kHz line rates at 3k resolution and 128x greater sensitivity. Featured with high speed and high sensitivity, these cameras are ideal for demanding applications such as flat panel inspection, wafer inspection, printed circuit board inspection, and high-performance document scanning.

RESOLUTION (HxV)3200 × 128

Sensor TypeVieworks

InterfaceGigE

ChromaColor

M42-mount based 3k / 4k / 6k TDI Line Scan Cameras
GigE Interface
Bidirectional Operation with up to 256 TDI Stages
Exposure Control
Advanced DSNU and PRNU Correction
Trigger Rescaler and Strobe Output Control

Flat Panel Display Inspection
PCB Inspection
High Performance Document Scanning
Wafer Inspection

Model	VT-3K7G-E38A-32	VT-3K7G-138A-128	VT-4K5G-E26A-64	VT-4K5G-H26A-256	VT-6K3.5G-E19A-64	VT-6K3.5G-H19A-256
Resolution (H × V)	3200 × 32	3200 × 128	4640 × 64	4640 × 256	6560 × 64	6560 × 256
Sensor	Hybrid TDI Line Scan
Pixel Size	7.0 μm × 7.0 μm		5.0 μm × 5.0 μm		3.5 μm × 3.5 μm
Interface	GigE
Max. Line Rate	35 kHz		25 kHz		18 kHz
Min. Line Rate	1 kHz
Pixel Format	8/10/12 bit
TDI Stages	32	32/64/96/128	64	64/128/192/256	64	64/128/192/256
Trigger Synchronization	Free-Run, External
Throughput	0.12 GPix/s
Gamma Correction	User Defined LUT (Lookup Table)
Black Level Control	-255 ~ 255 at 8 bit
Gain Control	Analog Gain: 1×, 2×, 3×, 4× / Digital Gain: 1.0× ~ 8.0×
Lens Mount	M42 × 1 mm (C or F-mount available upon request)
Dimension/Weight	60 mm × 60 mm × 36 mm, 223 g
Temperature	Ambient Operating: 0°C ~ 50°C (Housing: 10°C ~ 50°C), Storage: -40°C ~ 70°C
Power External	10 ~ 30 V DC
Power Dissipation	Typ. 3.5 W		Typ. 4.0 W		Typ. 4.5 W
Compliance	CE, FCC, KC, UKCA		CE, FCC, KC
API SDK	Vieworks Imaging Solution 7.XX

VT-3K7G-H38 DATASHEET
