VP-50MX-M 30

The VP-50MX-30 is a 50 megapixel CMOS camera available with the CoaXPress interface. This camera is based on the latest CMOS image sensor technology (CMV50000) from AMS CMOSIS. The VP-50MX-30 offers up to 30.9 frames per second at 7920 x 6004 resolution. This camera uses Thermoelectric Peltier (TEC) cooling technology developed for and used by many demanding medical market customers. The TEC maintains the operating temperature of the image sensor at up to 12±2℃ below ambient temperature. The VP-50MX camera provides a stable operating condition and the ability to expose for a long period of time to increase the camera’s sensitivity. Featuring high-speed and high-resolution with stable performance, this camera is ideal for demanding applications such as FPD, PCB and semiconductor inspections.

RESOLUTION (MP)50

RESOLUTION (HxV)7920 x 6004

FPS30

Sensor TypeCMV50000

InterfaceCXP-6

ChromaMono

Thermoelectric Peltier Cooled – 12±2℃ below
50 Megapixel Resolution
CoaXPress Interface up to 30.9 fps at 25 Gbps using 4 CH
Flat Field Correction with Sequencer Control
PRNU Correction
DSNU Correction
Defective Pixel Correction

Flat Panel Display Inspection
PCB Inspection
Machine Vision Inspection
Microscopy and Metrology

Model	VP-50MX-M/C 30
Resolution (H × V)	7920 × 6004
Sensor	AMS CMOSIS CMV 50000
Sensor Size (Diagonal)	35 mm (45.72 mm)
Sensor Type	High Speed CMOS Image Sensor
Pixel Size	4.6 μm × 4.6 μm
Interface	CoaXPress
Max. Frame Rate	1 CH: 7.7 fps @ 6.25 Gbps
	2 CH: 15.5 fps @ 6.25 Gbps
	4 CH: 30.9 fps @ 6.25 Gbps
Exposure Time (1 μs step)	1 μs ~ 60 s
Partial Scan (Max. Speed)	3968 fps at 4 Lines
Pixel Data Format	Mono: Mono 8 / Mono 10 / Mono 12
Pixel Data Format	Color: BG Bayer 8 / BG Bayer 10 / BG Bayer 12
Electronic Shutter	Global Shutter
Trigger Synchronization	>Free-Run, Hardware Trigger, Software Trigger or CXP
External Trigger	3.3 V ~ 24.0 V, 10 mA, Logical Level Input, Optically Isolated
Software Trigger	Asynchronous, Programmable via Camera API
Dynamic Range	64 dB
Gain Control	1× ~ 30× (1/1024 step)
Black Level Control	0 ~ 256 LSB at 12 bit (1 LSB step)
Cooling Method	Thermoelectric Peltier Cooling
Cooling Performance	12°C below ambient temperature – Standard cooling with a fan
Dimension / Weight	90 mm × 90 mm × 146 mm, 1,400 g (with F-mount)
Temperature	Operating: -5°C ~ 40°C, Storage: -40°C ~ 70°C
Lens Mount	F-mount, Custom mount available upon request
Vibration / Shock	3G (20 ~ 200 Hz) XYZ / 10G 6 ms
Power	External: 10 ~ 24 V DC
Power	Dissipation: Typ. 24.0 W
Compliance	CE, FCC, KC
API SDK	Vieworks Imaging Solution 7.X

VP-50MX-M 30 DATASHEET
