| Resolution (MP) | 101 | ||
| Resolution (H x V) | 11648 x 8742 | ||
| Sensor | Sony IMX 461 | ||
| Sensor Size (Diagonal) | 43.80 mm x 32.87 mm (55.0 mm) | ||
| Optical Format | 3.4” | ||
| Sensor Type | High Speed CMOS Image Sensor | ||
| Pixel Size | 3.76 µm x 3.76 µm | ||
| Interface | CoaXPress (CXP-3 / CXP-6) | ||
| Max Frame Rate | 8.7 fps (Overlapped Acquisition) | ||
| Binning | Sensor | x1, x3 (Horizontal and Vertical Dependent) | |
| Logic | x1, x2, x4 (Horizontal and Vertical Dependent) | ||
| Exposure Time (1 µs step) | 1 µs – 60 s | ||
| Pixel Data Format | 8 / 10 / 12 / 14 / 16 bit | ||
| Electronic Shutter | Rolling | ||
| Trigger Synchronization | Overlapped | Free-Run | |
| Non-Overlapped | Hardware Trigger, Software Trigger or CXP | ||
| Dynamic Range | 78 dB | ||
| Gain Control | 1x – 32x | ||
| Black Level Control | 0 – 4095 LSB at 16 bit | ||
| Dimension | 90.0 mm x 90.0 mm x 92.5 mm | ||
| Weight | 800 g | ||
| Temperature | Operating: 0° C – 40° C | Storage: -40° C – 70° C | |
| Lens Mount | M72 Mount | ||
| Power | 11 – 24 V DC
Typ 15.5 W |
||
| Compliance | CE, FCC, KC | ||
