VC-127MC-C 6 H

Resolution (MP)

127

Resolution (H x V)

13376 x 9528

Sensor

Sony IMX 661

Sensor Size (Diagonal)

46.15 mm x 32.87 mm (56.73 mm)

Optical Format

3.6”

Sensor Type

High Speed CMOS Image Sensor

Pixel Size

3.45 µm x 3.45 µm

Interface

Camera Link Base / Medium / Full / 10 Tap

Max Frame Rate

2 Tap:

1.2 fps

4 Tap:

2.5 fps

8 Tap:

5.0 fps

10 Tap:

6.2 fps

Exposure Time (1 µs step)

22.72 µs – 60 s

Binning

Sensor (12,14 bit)

x1, x2 (Horizontal and Vertical Dependent)

Logic

x1, x2, x4 (Horizontal and Vertical Dependent)

Pixel Data Format

Mono

Mono 8 / 10 / 12 bit

Color

RG Bayer 8 / 10 / 12 bit

Electronic Shutter

Global

Exposure Mode

Timed, Trigger Width

Dynamic Range

78 dB

Data Output Pixel Clock Speed

65 MHz / 85 MHz

Gain Control

Analog

1x – 12x

Digital

1 x – 32x

Black Level Control

0 – 255 LSB at 12 bit

Dimension

100.0 mm x 100.0 mm x 81.0 mm

Weight

1.01 kg

Temperature

Operating: 0° C – 40° C

Storage: -40° C – 70° C

Lens Mount

M72 Mount

Power

11 – 24 V DC

Typ 25.5 W

Compliance

CE, FCC, KC
