Resolution (MP) |
12 |
|
|
Resolution (H x V) |
4069 x 3072 |
|
|
Sensor |
CMOSIS CMV 12000 |
|
|
Sensor Size (Diagonal) |
22.5 mm x 16.9 mm (28.1 mm) |
|
|
Optical Format |
— |
|
|
Sensor Type |
High Speed CMOS Image Sensor |
|
|
Pixel Size |
4.5 µm x 4.5 µm |
|
|
Interface |
Camera Link |
|
|
Max Frame Rate |
2 Tap: |
13.0 fps |
|
|
4 Tap: |
26.0 fps |
|
|
8 Tap: |
51.7 fps |
|
|
10 Tap: |
64.3 fps |
|
Transfer Time |
2 Tap: |
76.9 ms |
|
|
4 Tap: |
38.5 ms |
|
|
8 Tap: |
19.4 ms |
|
|
10 Tap: |
15.6 ms |
|
Pixel Data Format |
8 bit (2/4/8/10 Tap) 10 bit (2/4/8 Tap) |
|
|
Electronic Shutter |
Global |
|
|
Digital Gain |
1x – 32x |
|
|
Black Level Control |
0 – 255 LSB at 12 bit (1 LSB step) |
|
|
Data Output Pixel Clock Speed |
85 MHz |
|
|
Trigger Mode |
Free Run, Trigger Programable Exposure Time and Trigger Polarity |
|
|
Dynamic Range |
60 dB |
|
|
Dimension |
68 mm x 68 mm x 80 mm |
|
|
Weight |
432 g |
|
|
Temperature |
Operating: 0° C – 40° C |
Storage: -40° C – 70° C |
|
Lens Mount |
F Mount |
|
|
Power |
10 – 14 V DC Typ 5 W |
|
|
Compliance |
CE, FCC, KC, UL |
|
