Resolution (MP) |
12 |
||
|
Resolution (H x V) |
4096 x 3072 |
||
|
Sensor |
CMOSIS CMV 12000 |
||
|
Sensor Size (Diagonal) |
22.5 mm x 16.9 mm (28.1 mm) |
||
|
Optical Format |
APS Like |
||
|
Sensor Type |
High Speed CMOS Image Sensor |
||
|
Pixel Size |
5.5 µm x 5.5 µm |
||
|
Interface |
CoaXPress |
||
|
Max Frame Rate |
4 CH: 188 fps @ 6.25 Gbps |
||
|
|
8 CH: 335 fps @ 6.25 Gbps |
||
|
Exposure Time (1 µs step) |
16 µs – 60 s |
||
|
Partial Scan (Max Speed) |
27777 fps at 4 Lines (H: 256) |
||
|
Pixel Data Format |
8 bit |
||
|
Electronic Shutter |
Global |
||
|
Gain Control |
1x – 4x |
||
|
Black Level Control |
0 – 16 LSB at 8 bit |
||
|
Trigger Synchronization |
Free Run, Timed, Trigger Width |
||
|
Dynamic Range |
54 dB |
||
|
Dimension |
90 mm x 90 mm x 114 mm |
||
|
Weight |
745 g |
||
|
Temperature |
Operating: 0° C – 40° C |
Storage: -40° C – 70° C |
|
|
Lens Mount |
F Mount |
||
|
Power |
External |
8 – 30 V DC Typ 18 W |
|
|
|
PoCXP |
24 V DC, Minimum of two PoCXP cables required |
|
|
Compliance |
CE, FCC, KC |
||
