Resolution (MP) |
151 |
||
|
Resolution (H x V) |
14192 x 10640 |
||
|
Sensor |
Sony IMX 411 |
||
|
Sensor Size (Diagonal) |
53.36 mm x 40.01 mm (66.7mm) |
||
|
Optical Format |
4.2” |
||
|
Sensor Type |
High Speed CMOS Image Sensor |
||
|
Pixel Size |
3.76 µm x 3.76 µm |
||
|
Interface |
CoaXPress (CXP-3 / CXP-6) |
||
|
Max Frame Rate |
6.2 fps (Overlapped Acquisition) |
||
|
Binning |
Sensor |
x1, x3 (Horizontal and Vertical Dependent) |
|
|
|
Logic |
x1, x2, x4 (Horizontal and Vertical Dependent) |
|
|
Exposure Time (1 µs step) |
1 µs – 60 s |
||
|
Pixel Data Format |
8 / 10 / 12 / 14 / 16 bit |
||
|
Electronic Shutter |
Rolling |
||
|
Trigger Synchronization |
Overlapped |
Free-Run |
|
|
|
Non-Overlapped |
Hardware Trigger, SoftwareTrigger or CXP |
|
|
Dynamic Range |
78 dB |
||
|
Gain Control |
1x – 32x |
||
|
Black Level Control |
0 – 4095 LSB at 16 bit |
||
|
Dimension |
100.0 mm x 100.0 mm x 92.5 mm |
||
|
Weight |
1070 g |
||
|
Temperature |
Operating: 0° C – 40° C |
Storage: -40° C – 70° C |
|
|
Lens Mount |
M72 Mount |
||
|
Power |
11 – 24 V DC Typ 15.5 W |
||
