| Resolution (MP) | 17 | ||
| Resolution (H x V) | 5440 x 3076 | ||
| Sensor | Sony IMX 387 | ||
| Sensor Size (Diagonal) | 18.76 mm x 10.61 mm (21.7 mm) | ||
| Optical Format | 4/3” | ||
| Sensor Type | High Speed CMOS Image Sensor | ||
| Pixel Size | 3.45 µm x 3.45 µm | ||
| Interface | CoaXPress | ||
| Max Frame Rate | 8 bit | 61.3 fps | |
| 10 bit | 56.5 fps | ||
| 12 bit | 40.4 fps | ||
| Exposure Time (1 µs step) | 2.4 µs – 60 s | ||
| Partial Scan (Max Speed) | 1724.0 fps at 4 Lines | ||
| Pixel Data Format | Mono | Mono 8 / mono 10 / Mono 12 | |
| Color | RG Bayer 8 / RG Bayer 10 / RG Bayer 12 | ||
| Electronic Shutter | Global | ||
| Gain Control | 1x – 32x | ||
| Black Level Control | 0 – 255 LSB at 12 bit | ||
| Trigger Synchronization | Free Run, Hardware Trigger, Software Trigger or CXP | ||
| External Trigger | 3.3 V – 24.0 V, 10 mA, Logical Level Input, Optically Isolated | ||
| Software Trigger | Asynchronous, Programmable via Camera API | ||
| Dynamic Range | 72 dB | ||
| Dimension | 68 mm x 68 mm x 105 mm | ||
| Weight | 550 g | ||
| Temperature | Operating: 0° C – 40° C | Storage: -40° C – 70° C | |
| Lens Mount | F Mount | ||
| Power | External | 11 – 24 V DC Typ 17 W | |
| PoCXP | 24 V DC, Minimum of two PoCXP cables required | ||
| Compliance | CE, FCC, KC | ||
