VC-18MX2-C 132

Resolution (MP)

18

Resolution (H x V)

4480 x 4096

Sensor

Gpixel GMAX 2518

Sensor Size (Diagonal)

11.27 mm x 10.24 mm (15.22 mm)

Optical Format

1”

Sensor Type

High Speed CMOS Image Sensor

Pixel Size

2.5 µm x 2.5 µm

Interface

CoaXPress 2.0

Max Frame Rate

132 fps

Exposure Time (1 µs step)

1 µs – 60 s

Partial Scan (Max Speed)

14101.0 fps at 2 Lines (8 bit)

Pixel Data Format

Mono 8 / 10 bit

Color GB Bayer 8 / 10 bit

Electronic Shutter

Global

Digital Gain

1x – 32x

Black Level Control

0 – 63 LSB at 10 bit (1 LSB step)

Trigger Synchronization

Free Run, Timed, Trigger Width

External Trigger

3.3 V – 24.0 V, 10 mA, Logical Level Input, Optically Isolated

Software Trigger

Asynchronous, Programmable via Camera API

Dynamic Range

62 dB

Dimension

50 mm x 50 mm x 87 mm

Weight

270 g

Temperature

Operating: 0° C – 40° C

Storage: -40° C – 70° C

Lens Mount

C Mount

Power

External

11 – 14 V DC, Typ 16 W

PoCXP

24 V DC, Minimum of two PoCXP cables required

Compliance

CE, FCC, KC
