| Resolution (MP) | 18 | ||
| Resolution (H x V) | 4480 x 4096 | ||
| Sensor | Gpixel GMAX 2518 | ||
| Sensor Size (Diagonal) | 11.27 mm x 10.24 mm (15.22 mm) | ||
| Optical Format | 1” | ||
| Sensor Type | High Speed CMOS Image Sensor | ||
| Pixel Size | 2.5 µm x 2.5 µm | ||
| Interface | CoaXPress 2.0 | ||
| Max Frame Rate | 132 fps | ||
| Exposure Time (1 µs step) | 1 µs – 60 s | ||
| Partial Scan (Max Speed) | 14101.0 fps at 2 Lines (8 bit) | ||
| Pixel Data Format | Mono 8 / 10 bit
Color GB Bayer 8 / 10 bit |
||
| Electronic Shutter | Global | ||
| Digital Gain | 1x – 32x | ||
| Black Level Control | 0 – 63 LSB at 10 bit (1 LSB step) | ||
| Trigger Synchronization | Free Run, Timed, Trigger Width | ||
| External Trigger | 3.3 V – 24.0 V, 10 mA, Logical Level Input, Optically Isolated | ||
| Software Trigger | Asynchronous, Programmable via Camera API | ||
| Dynamic Range | 62 dB | ||
| Dimension | 50 mm x 50 mm x 87 mm | ||
| Weight | 270 g | ||
| Temperature | Operating: 0° C – 40° C | Storage: -40° C – 70° C | |
| Lens Mount | C Mount | ||
| Power | External | 11 – 14 V DC, Typ 16 W | |
| PoCXP | 24 V DC, Minimum of two PoCXP cables required | ||
| Compliance | CE, FCC, KC | ||
Contact VST today for your free quote or with any questions!
