| Resolution (MP) | 25 | ||
| Resolution (H x V) | 5120 x 5120 | ||
| Sensor | Gpixel GMAX 0505 | ||
| Sensor Size (Diagonal) | 12.8 mm x 12.8 mm (18.1 mm) | ||
| Optical Format | 1.1” | ||
| Sensor Type | High Speed CMOS Image Sensor | ||
| Pixel Size | 2.5 µm x 2.5 µm | ||
| Interface | CoaXPress | ||
| Max Frame Rate | 1 CH: 23.1 fps | ||
| 2 CH: 41.7 fps | |||
| Exposure Time (1 µs step) | 1 µs – 60 s | ||
| Partial Scan (Max Speed) | 6144.4 fps at 64 x 2 | ||
| Pixel Data Format | Mono 8 bit, Mono 10 bit | ||
| Electronic Shutter | Global | ||
| Gain Control | 1x – 32x | ||
| Black Level Control | 0 – 63 LSB at 10 bit | ||
| Trigger Synchronization | Free Run, Hardware Trigger, Software Trigger or CXP | ||
| External Trigger | 3.3 V – 24.0 V, 10 mA, Logical Level Input, Optically Isolated | ||
| Software Trigger | Asynchronous, Programmable via Camera API | ||
| Dynamic Range | 60 dB | ||
| Dimension | 50 mm x 50 mm x 68 mm | ||
| Weight | 220 g | ||
| Temperature | Operating: -5° C – 40° C | Storage: -40° C – 70° C | |
| Lens Mount | C Mount | ||
| Power | External | 11 – 24 V DC Typ 8.0 W | |
| PoCXP | 24 V DC, CH 1 only | ||
Contact VST today for your free quote or with any questions!
