Resolution (MP) |
71 |
||
|
Resolution (H x V) |
10000 x 7096 |
||
|
Sensor |
CMOSIS CHR71000 |
||
|
Sensor Size (Diagonal) |
31.00 mm x 22.00 mm (38mm) |
||
|
Optical Format |
35 mm |
||
|
Sensor Type |
High Speed CMOS Image Sensor |
||
|
Pixel Size |
3.1 µm x 3.1 µm |
||
|
Interface |
Camera Link Base |
||
|
Max Frame Rate |
CL Base: |
2.1 fps |
|
|
|
CL Medium: |
3.0 fps |
|
|
|
CL Medium Overclocked: |
4.2 fps |
|
|
Exposure Time (1 µs step) |
66 µs – 7 s (1 line step) |
||
|
Transfer Time |
476 ms (CL Base) 335 ms (CL Medium) 238 ms (CL Medium Overclocked) |
||
|
Data Output Pixel Clock Speed |
2 Tap |
85 MHz |
|
|
|
4 Tap |
65 MHz |
|
|
Pixel Data Format |
8 / 10 / 12 bit |
||
|
Electronic Shutter |
Rolling |
||
|
Dynamic Range |
78 dB |
||
|
Trigger Mode |
Free-Run, External Trigger |
||
|
|
Programmable Exposure Time and Trigger Polarity |
||
|
Dimension |
68.0 mm x 68.0 mm x 103.0 mm |
||
|
Weight |
420 g |
||
|
Temperature |
Operating: 0° C – 40° C |
Storage: -40° C – 70° C |
|
|
Lens Mount |
F Mount |
||
|
Power |
10 – 38 V DC Typ 7.5 W |
||
|
Compliance |
CE, FCC, KC |
||
