| Resolution (MP) | 9 | |
| Resolution (H x V) | 4200 x 2160 | |
| Sensor | Gpixel GMAX 2509 | |
| Sensor Size (Diagonal) | 10.5 mm x 5.4 mm (11.8 mm) | |
| Optical Format | 2/3” | |
| Sensor Type | High Speed CMOS Image Sensor | |
| Pixel Size | 2.5 µm x 2.5 µm | |
| Interface | Camera Link Base / Medium / Full / 10 Tap | |
| Max Frame Rate | 2 Tap: | 18.4 fps |
| 4 Tap: | 36.5 fps | |
| 8 Tap: | 72.0 fps | |
| 10 Tap: | 90.7 fps | |
| Exposure Time (1 µs step) | 1 µs – 60 s | |
| Partial Scan (Max Speed) | 8796.2 fps at 2 Lines
(10 Tap) |
|
| Pixel Data Format | GE Bayer 8 / 10 / 12 | |
| Electronic Shutter | Global | |
| Digital Gain | 1x – 32x | |
| Black Level Control | 0 – 255 LSB at 12 bit (1 LSB step) | |
| Exposure Mode | Free-Run, Timed, Trigger Width | |
| External Trigger | 3.3 V – 24.0 V, 10 mA, Logical Level Input Optically Isolated, CC1 | |
| Software Trigger | Asynchronous, Programable via Camera API | |
| Dynamic Range | 65 dB | |
| Dimension | 40.0 mm x 40.0 mm x 51.0 mm | |
| Weight | 130 g | |
| Temperature | Operating: 0° C – 40° C | Storage: -40° C – 70° C |
| Lens Mount | C Mount | |
| Power | 11 – 24 V DC
Typ 6 W |
|
| Compliance | CE, FCC, KC | |
