VL-2K7C-C100 I-2

Resolution (H x V)

2048 x 2

Sensor

Vieworks

Pixel Size

7.0 µm x 7.0 µm

Interface

Camera Link Base / Medium / Full / 10 Tap

Max Line Rate

100 kHz

Data Output Mode

2 Tap

8 / 10 / 12 bit

3 Tap

8 / 10 / 12 bit

4 Tap

8 / 10 / 12 bit

6 Tap

8 bit

8 Tap

8 bit

10 Tap

8 bit

Exposure Time

1.00 – 1000.0 µs

Pixel Data Format

Bicolor RGBG 8/10/12 RGB 8/10/12 BGR 8/10/12

Camera Link Pixel Clock Speed

45 / 65 / 85 MHz

Binning

Sensor

N/A

Logic

1 X 2, 2 X 2

Trigger Synchronization

Free Run, Hardware Trigger, CC1

External Trigger

3.3 V – 5.0 V

Dynamic Range

62 dB

Black Level Control

From 4096 to 4095 LSB at 12 bits

Gain Control

Analog

1.25x, 1.75x, 2.00x, 3.00x, 4.00x

Digital

1.00x – 32.00x

Dimension

60.0 mm x 60.0 mm x 37.1 mm

Weight

224 g

Temperature

Operating: 0° C – 40° C

Storage: -40° C – 70° C

Lens Mount

M42 x 1 mm

Power

External

10 – 30 V DC, Typ 6.8 W

PoCL

PoCL Compliant – Two PoCL cables required

Compliance

CE, FCC, KC, UKCA, UL
