Resolution (H x V) |
4096 x 2 |
||
|
Sensor |
Gpixel GL0402 |
||
|
Pixel Size |
7.0 µm x 7.0 µm |
||
|
Interface |
Camera Link Base / Medium / Full / 10 Tap |
||
|
Max Line Rate |
200 kHz |
||
|
Data Output Mode |
2 Tap |
8 / 10 / 12 bit |
|
|
3 Tap |
8 / 10 / 12 bit |
||
|
4 Tap |
8 / 10 / 12 bit |
||
|
8 Tap |
8 bit |
||
|
10 Tap |
8 bit |
||
|
Exposure Time |
1.00 – 1000.0 µs |
||
|
Pixel Data Format |
Mono 8 / Mono 10 / Mono 12 |
||
|
Camera Link Pixel Clock Speed |
45 / 65 / 85 MHz |
||
|
Trigger Synchronization |
Free Run, Hardware Trigger, CC1 |
||
|
External Trigger |
3.3 V – 5.0 V |
||
|
Dynamic Range |
62 dB |
||
|
Black Level Control |
From 4096 to 4095 LSB at 12 bits |
||
|
Gain Control |
Analog |
1.25x, 1.75x, 2.00x, 3.00x, 4.00x |
|
|
Digital |
1.00x – 32.00x |
||
|
Dimension |
60.0 mm x 60.0 mm x 37.1 mm |
||
|
Weight |
224 g |
||
|
Temperature |
Operating: 0° C – 40° C |
Storage: -40° C – 70° C |
|
|
Lens Mount |
M42 x 1 mm |
||
|
Power |
External |
10 – 30 V DC, Typ 6.8 W |
|
|
PoCL |
PoCL Compliant – Two PoCL cables required |
||
|
Compliance |
CE, FCC, KC |
||
