| Resolution (H x V) | 1x (1 Shot) | 12000 x 12000 | |
| 4x (4 Shot) | 24000 x 24000 | ||
| Sensor | Syncron DCS144M | ||
| Sensor Size (Diagonal) | 42.0 mm x 42.0 mm (59.39 mm) | ||
| Optical Format | — | ||
| Sensor Type | High Speed CMOS Image Sensor | ||
| Pixel Size | 3.5 µm x 3.5 µm | ||
| Interface | CoaXPress 2.0 (CXP-6/10/12) | ||
| Max Frame Rate | 15 fps at 8 bit | ||
| Exposure Time (1 µs step) | 1 µs – 60 s | ||
| Pixel Data Format | Mono 8 / Mono 10 / Mono 12 | ||
| Electronic Shutter | Global | ||
| Gain Control | Analog | 1x – 4x | |
| Digital | 1x – 32x | ||
| Black Level Control | 0-255 LSB at 12 bit | ||
| Trigger Synchronization | Free Run, Hardware Trigger, Software Trigger, UserOutput0, CXP, Timer | ||
| Dynamic Range | 60 dB | ||
| Shift Range | 0-14 µm, 1 nm Step | ||
| Shift Resolution | 0.001 µm | ||
| Shift Control | Manual Mode or Sequence Mode | ||
| Shift Latency | < 5 ms | ||
| Cooling Performance | 10° ± 2° C Below Ambient Temp | ||
| Dimension | 125.0 mm x 125.0 mm x 157 mm | ||
| Weight | 3.4 kg | ||
| Temperature | Operating: 0° C – 40° C | Storage: -40° C – 70° C | |
| Lens Mount | M72 Mount | ||
| Power | 11 – 24 V DC, Typ 40 W | ||
