VP-127MX2-C 21H

The VC-127MX2, the latest model of the industrial proven VC series, is a new 127 megapixel CoaXPress camera and based on the CMOS global shutter image sensor technology (IMX661) from Sony. The VC-127MX2 offers up to 21.9 frames per second at 13376 × 9528 resolution. The camera comes with the next generation CoaXPress 2.0 (CXP-12) interface delivering up to 50 Gigabits per second over four coaxial cables. These combinations of the CMOS sensor technology and CoaXPress 2.0 interface set a new standard for industrial, scientific and surveillance digital imaging applications. Equipped with Vieworks innovative technology, trusted by the world’s top FPD manufacturers, the VC-127MX2 camera offers highly uniformed images with high-speed image processing capabilities. Featured with high-quality image uniformity and high-resolution, this camera is ideal for demanding applications such as FPD, PCB and semiconductor inspections.

RESOLUTION (MP)127

RESOLUTION (HxV)13376 x 9528

FPS21.9

Sensor TypeIMX466

InterfaceCXP-12

ChromaColor

127 Megapixel Resolution
Global Shutter CMOS Technology
CoaXPress 2.0 Interface up to 21.9 fps at 50 Gbps using 4 CH
DSNU and PRNU Correction
Defective Pixel Correction
Hot Pixel Correction
Flat Field Correction with Sequencer Control

Flat Panel Display Inspection
Electronics Inspection
Semiconductor Inspection
Document / Film Scanning

Model	VP-127MX2-M/C21H
Resolution (H × V)	13376 × 9528
Sensor	SONY IMX661
Sensor Size (Diagonal)	46.15 mm × 32.87 mm (56.73 mm)
Pixel Size	3.45 μm × 3.45 μm
Interface	CoaXPress 2.0 (CXP-6/10/12)
Max. Frame Rate	1 CH: 8.8 fps
	2 CH: 17.9 fps
	4 CH: 21.9 fps
Exposure Time (1 μs step)	1 μs ~ 60 s
Binning	Sensor (12, 14 bit): Horizontal and Vertical Dependent: ×1, ×2
Binning	Logic: Horizontal and Vertical Independent: ×1, ×2, and ×4 (Mono Only)
Pixel Data Format	Monochrome: 8/10/12/14 bit
Pixel Data Format	Color: RG Bayer 8/10/12/14 bit
Electronic Shutter	Global Shutter
Exposure Mode	Timed, Trigger Width
Dynamic Range	73 dB @ 14 bit
Gain Control	Analog: 1× ~ 12×
Gain Control	Digital: 1× ~ 32×
Black Level Control	0 ~ 1023 LSB @ 14 bit
Dimension / Weight	110 mm × 110 mm × 89 mm, 1.45 kg (with M-72 mount)
Cooling Performance	15±2°C below ambient temperature – Standard cooling with a fan
Temperature	Operating: 0°C ~ 40°C, Storage: -40°C ~ 70°C
Trigger Synchronization	Free-Run, Hardware Trigger, Software Trigger, UserOutput0, CXP, Timer
External Trigger	3.3 V ~ 24.0 V, 10 mA, Logical Level Input, Optically Isolated
Software Trigger	Asynchronous, Programmable via Camera API
Lens Mount	M72-mount, Custom mount available upon request
Power	External: 11 ~ 24 V DC
Power Dissipation	Typ. 36 W
Compliance	CE, FCC, KC
API SDK	Vieworks Imaging Solution 7.X

VP-127MX2-C 21H DATASHEET
