VP-25MC-M 30

The VP-25MC camera is a 25 megapixel resolution CMOS camera with the Camera Link interface. It features 25 megapixel resolutions with frame rate up to 30 fps. This camera uses Thermoelectric Peltier (TEC) cooling technology developed for, and used by, many demanding medical market customers. The TEC maintains the operating temperature of the CMOS image sensor at up to about 17 degrees below ambient temperature. This camera provides a stable operating condition or the ability to expose for a long period of time to increase camera sensitivity. Featured with the stable operating capability and high resolution, this camera is ideal for demanding applications such as FPD, PCB and semiconductor inspections.

RESOLUTION (MP)25

RESOLUTION (HxV)5120 x 5120

FPS30.9

Sensor TypeVITA25K

InterfaceCamera Link

ChromaMono

25 Megapixel Resolution (ON Semiconductor)
Thermoelectric Peltier Cooling-about 17 degrees below ambient temperature
Minimizing the number of hot pixels with TEC (up to 99%)
Camera Link Full Interface*Pixel Defect Correction
Flat Field Correction
Field Upgradable Firmware

Flat Panel Display Inspection
Research and Scientific Imaging
Machine Vision Inspection
Microscopy and Metrology

Resolution (MP)	25
Resolution (H x V)	5120 x 5120
Sensor	ON Semi VITA-25K
Sensor Size (Diagonal)	23.04 mm x 23.04 mm (32.58 mm)
Optical Format	35 mm
Sensor Type	High Speed CMOS Image Sensor
Pixel Size	4.5 µm x 4.5 µm
Interface	Camera Link Full
Max Frame Rate	8 Tap:	25.0 fps
	10 Tap:	30.9 fps
Transfer Time	8 Tap:	40.00 ms
	10 Tap:	32.36 ms
Exposure Time	1/100,000 – 7 s
Pixel Data Format	8 bit (8/10 Tap), 10 bit (8 Tap)
Electronic Shutter	Global
Binning	1X and 2X
Data Output Pixel Clock Speed	85 MHz
Trigger Mode	Free-Run
	Programmable Exposure Time and Trigger Polarity
Dynamic Range	54 dB
Cooling Method	Thermoelectric Peltier Cooling
Cooling Performance	17° C below ambient temperature / Standard cooling with fan
Dimension	90.0 mm x 90.0 mm x 134.0 mm
Weight	1500 g
Temperature	Operating: -5° C – 40° C	Storage: -40° C – 70° C
Lens Mount	F Mount
Power	10 – 24 V DC Typ 22 W
Compliance	CE, FCC, KC

VP-25MC-M 30 DATASHEET
