VP-31MC-C 26 H

The VP-31MC-26 H is a 31 megapixel CMOS camera available with the Camera Link interface. This camera is based on the latest CMOS image sensor technology (IMX342) from Sony Semiconductor Solutions Corporation. The VP-31MC-26 H offers up to 26.2 frames per second at 6464 × 4852 resolution. This camera uses Thermoelectric Peltier (TEC) cooling technology developed for and used by many demanding medical market customers. The TEC maintains the operating temperature of the image sensor at up to 15±2℃ below ambient temperature. The VP-31MC camera provides a stable operating condition and the ability to expose for a long period of time to increase the camera’s sensitivity. Featuring high-speed and high-resolution with stable performance, this camera is ideal for demanding applications such as FPD, PCB and semiconductor inspections.

RESOLUTION (MP)31

RESOLUTION (HxV)6464 x 4852

FPS26.2

Sensor TypeIMX342

InterfaceCamera Link

ChromaColor

Thermoelectric Peltier Cooled – 15±2℃ below
31 Megapixel Resolution
Camera Link Full Interface
Flat Field Correction with Sequencer Control
PRNU Correction
Hot Pixel Correction and Defective Pixel Correction
Frame Averaging
GenICam Compatible – XML based Control

Flat Panel Display Inspection
Electronics Inspection
Semiconductor Inspection
Document and Film Scanning

Resolution (MP)		31
Resolution (H x V)		6464 x 4852
Sensor		Sony IMX342
Sensor Size (Diagonal)		23.30 mm x 16.73 mm (27.9 mm)
Optical Format		APS-C
Sensor Type		High Speed CMOS Image Sensor
Pixel Size		3.45 µm x 3.45 µm
Interface		Camera Link Base / Medium / Full / 10 Tap
Max Frame Rate	2 Tap	5.3 fps
	4 Tap	10.6 fps
	8 Tap (8 bit)	21.1 fps
	10 Tap (8 bit)	26.2 fps
Exposure Time		2.4 µs – 60 s
Partial Scan (Max Speed)		1442.3 fps @ 4 Lines
Binning		X1, X2 (Horizontal and Vertical Dependent)
Pixel Data Format	Mono	Mono 8 / Mono 10 / Mono 12
	Color	RG Bayer 8 / RG Bayer 10 / RG Bayer 12
Data Output Pixel Clock Speed		65 MHz / 85 MHz
Electronic Shutter		Global
Trigger Synchronization		Free-Run, Hardware Trigger, Software Trigger or CC1
External Trigger		3.3 V – 24.0 V, 10 mA, Logical Level Input, Optically Isolated
Software Trigger		Asynchronous, Programmable via Camera API
Dynamic Range		72 dB
Cooling Method		Thermoelectric Peltier Cooling
Cooling Performance		15° ± 2° C below ambient temperature / Standard cooling with fan
Dimension		90.0 mm x 90.0 mm x 129.3 mm
Weight		1256 g
Temperature		Operating: 0° C – 40° C	Storage: -40° C – 70° C
Lens Mount		F Mount
Power		11 – 24 V DC Typ 30 W
Compliance		CE, FCC, KC

VP-31MC-C 26 H DATASHEET
