VP-31MC-M 26 H

Resolution (MP)

31

Resolution (H x V)

6464 x 4852

Sensor

Sony IMX342

Sensor Size (Diagonal)

23.30 mm x 16.73 mm (27.9 mm)

Optical Format

APS-C

Sensor Type

High Speed CMOS Image Sensor

Pixel Size

3.45 µm x 3.45 µm

Interface

Camera Link Base / Medium / Full / 10 Tap

Max Frame Rate

2 Tap

5.3 fps

4 Tap

10.6 fps

8 Tap (8 bit)

21.1 fps

10 Tap (8 bit)

26.2 fps

Exposure Time

2.4 µs – 60 s

Partial Scan (Max Speed)

1442.3 fps @ 4 Lines

Binning

X1, X2 (Horizontal and Vertical Dependent)

Pixel Data Format

Mono

Mono 8 / Mono 10 / Mono 12

Color

RG Bayer 8 / RG Bayer 10 / RG Bayer 12

Data Output Pixel Clock Speed

65 MHz / 85 MHz

Electronic Shutter

Global

Trigger Synchronization

Free-Run, Hardware Trigger, Software Trigger or CC1

External Trigger

3.3 V – 24.0 V, 10 mA, Logical Level Input, Optically Isolated

Software Trigger

Asynchronous, Programmable via Camera API

Dynamic Range

72 dB

Cooling Method

Thermoelectric Peltier Cooling

Cooling Performance

15° ± 2° C below ambient temperature / Standard cooling with fan

Dimension

90.0 mm x 90.0 mm x 129.3 mm

Weight

1256 g

Temperature

Operating: 0° C – 40° C

Storage: -40° C – 70° C

Lens Mount

F Mount

Power

11 – 24 V DC

Typ 30 W

Compliance

CE, FCC, KC
