VC-151MC-M 5 H

Resolution (MP)

151

Resolution (H x V)

14192 x 10640

Sensor

Sony IMX 411

Sensor Size (Diagonal)

53.36 mm x 40.01 mm (66.7mm)

Optical Format

4.2”

Sensor Type

High Speed CMOS Image Sensor

Pixel Size

3.76 µm x 3.76 µm

Interface

Camera Link Base / Medium / Full / 10 Tap

Max Frame Rate

5.5 fps (Overlapped Acquisition)

Binning

Sensor

x1, x3 (Horizontal and Vertical Dependent)

Logic

x1, x2, x4 (Horizontal and Vertical Dependent)

Exposure Time (1 µs step)

1 µs – 60 s

Data Output Pixel Clock Speed

85 MHz / 65 MHz

Pixel Data Format

8 / 10 / 12 bit

Electronic Shutter

Rolling

Trigger Synchronization

Overlapped

Free-Run

Non-Overlapped

Hardware Trigger or CC1

Dynamic Range

78 dB

Gain Control

1x – 32x

Black Level Control

0 – 255 LSB at 12 bit

Dimension

100.0 mm x 100.0 mm x 92.5 mm

Weight

1070 g

Temperature

Operating: 0° C – 40° C

Storage: -40° C – 70° C

Lens Mount

M72 Mount

Power

11 – 24 V DC

Typ 15.5 W

Compliance

CE, FCC, KC
